GPC
EcoSEC HIGH TEMPERATURE GPC SYSTEM
PERFORMANCE PROOF - APPLICATIONS
POLYPHENYLENESULFIDE (PPS)
Polyphenylene sulfide (PPS), an organic polymer consisting
of aromatic rings linked with sulfides, is effectively separat-
ed by ultra-high temperature GPC (Figure 6). Synthetic fiber
and textiles derived from this polymer are known to resist
chemical and thermal attack. PPS is used to make filter fab-
ric for coal boilers, papermaking felts, electrical insulation,
specialty membranes, gaskets, and packings. PPS has not
been found to dissolve in any solvent at temperatures be-
low about 200 °C (392 °F).
POLYMETHYLPENTENE (PMP)
The separation of polymethylpentene (PMP), a high perfor-
mance, heat resistant (mp > 200 C) polymer with charac-
teristics similar to polyolefins, is shown in Figure 7. PMP’s
exhibit excellent electrical insulating properties and strong
hydrolysis resistance. One of the principle applications is
for a release film used in the electronics industry.
-20
20
40
60
80
100
0
6 8 10 12 14 16 18 20 22 24 26
Retention time (minutes)
Column:
TSKgel GMH
HR
-H HT × 2
Mobile phase:
0.05% BHT in ODCB
Flow rate:
1 mL/min
Detector:
RI
Temperature:
145 ˚C
Concentration:
1.0 g/L
Injection vol.:
300 µL
Detector response (mV)
ANALYSIS OF POLYMETHYLPENTENE BY HIGH TEMPERATURE
GPC
Column: TSKgel GMH
HR
-H HT, 5 µm, 7.8 mm ID × 30 cm L × 2
Mobile phase: ODCB with 0.05% BHT; Flow rate: 1 mL/min;
Detector: RI (EcoSEC High Temperature GPC System); Temp.: 145 ˚C;
FIGURE 7
6 8 10 12 14 16 18 20 22 24 26
-40
-20
20
40
60
80
0
Retention time (minutes)
Column:
TSKgel GMH
HR
-H(S)HT2 × 2
Mobile phase:
1-Chloronaphthalene
Flow rate:
1.0 mL/min
Detector:
RI
Temperature:
220 ˚C
Concentration:
1.0 g/L
Injection vol.:
300 µL
Detector response (mV)
ANALYSIS OF POLYPHENYLENE SULFIDE BY ULTRA-HIGH
TEMPERATURE GPC
Column: TSKgel GMH
HR
-H(S) HT2, 13 µ , 7.8 mm ID × 30 cm L × 2
Mobile phas : 1-CN; Flow rate: 1.0 mL/min;
Detector: RI (EcoSEC High Temperature GPC System);
Temp.: 220 ˚C; Co centration: 1.0 g/L; Injection vol.: 300 µL
FIGURE 6
